N series planetary gear units are suitable for connecting large motor to reach rated power and maximum torque. Low speed shaft and high speed shaft can work with heavy load. Output torque: 5,000...800,000Nm Range of ratio: 3.4...2000 The relative position of input shaft and output shaft: coaxial/ corners Product Features: Flange installation, anti-impact force well Output shaft can choose heavy-duty bearing, also can choose spline or gear. Model of motor: can choose motor IEC and equipped with encoder and brake. It can choose Hydraulic Motor to input and furnished with hydraulic brake
| Coaxial output | one stage transmission | 200--353 |
| two stage transmission | 200-445 | |
| three stage transmission | 200-543 | |
| four stage transmission | 240--696 | |
| 90 degrees corner output | one stage transmission | 200--429 |
| two stage transmission | 200-543 | |
| three stage transmission | 240--696 |
Non-standard requirements for N series planetary gear units are as follows:
1. Change the ratio, and strength the bearing torque.
2. It is used in high position, underwater or spray environments
3. Changing the length and diameter of the output and input shaft, and process surface with anti-corrosion and inactivation.
4. It can equipped with DC motor, stepper motor, torque motor, water proof motor, Metallurgy lifting motor, variable-frequency motor, electromagnetic speed regulating motor and so on.
